600 AMP INDUSTRIAL AC + DC TRUE RMS CLAMP METER - CALIBRATED

Cat #: CMI-600-C
UPC #: 783310022299

600 AMP INDUSTRIAL AC + DC TRUE RMS CLAMP METER - CALIBRATED

Cat #: CMI-600-C
UPC #: 783310022299
  • CMI-600 with Certificate of Calibration
  • Measures AC+DC current and DC microamps
  • AC and AC+DC voltage measurements with digital filter low pass for accurate readings on variable frequency drives
  • Also measures DC voltage, resistance, capacitance, temperature and frequency
  • Tests continuity and diodes
  • Phase Sequence & Motor Rotation tests
  • Peak-RMS measures motor in rush current
  • Backlight & relative mode for added versatility
  • AmpTip™ increases accuracy on small wires and low current
  • Two voltage detection modes - non-contact or using a single test lead
  • Data hold
  • Recording of Maximum, Minimum, and Average readings
  • Lifetime warranty
Show Less
Read More
Register Your Product
Where to Buy

Specifications

Amperage Measurement 60, 600 Amps AC+DC
Display LCD, 6000 Count
Frequency Rating Voltage and AmpTip™ current: 50/60 Hz. High current: 50 to 400 Hz
Includes (2) 1.5V AAA batteries, test leads and clips, carrying case
Jaw Opening 1.18'' (30 mm)
Measurement Category CAT III 600V, CAT IV 300V
Replacement Part 02714 test leads and clips, TC-10 carrying case
Resistance Measurement 600, 6k, 60k Ohms
Standard CAT III, C/US UL Listed, CE
True Power AC+DC True RMS
Voltage Measurement 600 Volts AC+DC
*Greenlee® may make improvements and/or changes in the specifications of products at any time, in its sole discretion, without notice or obligation and further reserves the right to change or discontinue models.
