ClearTest® Transformer Tester

Cat #: CT-300
UPC #: 0783310556961

ClearTest® Transformer Tester

Cat #: CT-300
UPC #: 0783310556961
  • Quickly tests deenergized power distribution transformers
  • Briefly energizes the transformer and takes a snapshot of the condition by measuring the voltage, current and power factor of the test signal
  • The CT-300 is incompatible with dual voltage & multi-tap transformers. Inconsistent measurements will result. Recommend TILT II Transformer Tester as an alternative to the CT-300.
  • Tests overhead, pad-mount and distribution transformers
  • Audible alarm confirms successful test
  • Improve SAIDI statistics by quickly testing and getting the transformer back in service
  • Auto self-test performed with every test
  • Compact, lightweight and easy-to-use
Show Less
Read More
Request a Demo
Register Your Product
Request Info
Where to Buy

Specifications

Sub Brand HDE
Type Transformer Tester
Model ClearTest
Temperature Range -20°F to +140°F (-29°C to +60°C)
Output 500VDC or 5,000VDC nominal
Enclosure ABS UL 94-HB
Mounting Magnet
Size 7.8"L x 4"W x 2.3"H (19.5 cm x 10.1 cm x 5.9 xm)
Supply Current 1,000µA on 500VDC range; 100µA on 5,000VDC range; 2,000µA max
Included CT-300 Tester, B-9 Carrying Bag
*Greenlee® may make improvements and/or changes in the specifications of products at any time, in its sole discretion, without notice or obligation and further reserves the right to change or discontinue models.
